Soluxio NatureGuardâ„¢: Solar Wildlife Friendly Lighting
Wildlife and nocturnal friendly lighting
The Soluxio is the most advanced and well-designed solar light column on the market. This sustainable solar light pole is now also available in a wildlife-friendly edition. The Soluxio wildlife-friendly lighting edition is a 100% solar-powered and therefore operates completely off the grid. Because of this, invasive trenching and cutting concrete is no longer needed. As a result, the Soluxio solar wildlife-friendly lighting edition protects underground life and sustains healthy ecosystems.
Light improves public safety; however, considering animal life, it’s important not to use more light than necessary. Apart from this being a waste of energy, it also has a major impact on wildlife. With the Soluxio wildlife-friendly lighting edition, FlexSol has created specific solutions for locations where you need light, but you don’t want to interrupt the environment.
Product Specifications |
|
|---|---|
| Product name | Soluxio Solar Pole |
| Mounting height | 4 m to 10 m |
| Foundation type | 4-Bolt Base / Directly Buried |
| Operating temperature | -20 to 60 °C |
Column |
|
| Column material | Marine-grade aluminum EN AW 6063-T6 (other materials available on request) |
| Finish | Powder coating or anodizing (black, other colors on request) |
| Hand hole | 600 × 100 mm |
| Locking bolts | Triangular (default), security (optional) |
Soluxio Solar Module |
|
| Solar technology | Monocrystalline silicon solar cells |
| Amount of solar modules | Variable from 1 (SOL1) up to 4 (SOL4) |
| Cell efficiency | > 24% |
| Module power | > 110 Wp |
| Total system power | 110 to 440 Wp |
| Number of cells per module | 32 pcs |
| Number of strings per module | 4 strings |
| MPPT topology | Every string individually optimized for every individual module |
| Number of MPPT channels | 4 per solar module |
| Front sheet material | Borosilicate glass |
| Solar module colour | Black or white |
| Dimensions per module | Ø 200 × 1110 mm |
| Weight per module | 7 kg |
Soluxio Control Unit |
|
| Soluxio Control Unit | Containing control electronics and battery |
| Location | In pole, on C-rail |
| Material | Marine-grade aluminum EN AW 6060-T66 |
| Finishing | Anodized |
| Ingress protection | IP67 |
| Enclosure mounting | Optional padlock can be provided for the inside |
Soluxio Battery |
|
|---|---|
| Battery technology | Lithium (NMC) |
| Battery capacity | 850 Wh or 1275 Wh |
| Battery voltage | 14.9 Vdc (850 Wh) 22.3 Vdc (1275 Wh) |
| Battery SoC window | 10 to 95% |
| Service life | approx. 10 years |
| Operating temperature | -20 to 60 °C |
| Enclosure | Integrated in Soluxio Control Unit enclosure |
Soluxio Control Electronics |
|
| Battery Management System (BMS) | Integrated 6-cell monitoring and balancing |
| Control Electronics temperature and humidity monitoring | Integrated temperature sensor on-board lithium pack Integrated temperature sensor on-board electronics Integrated humidity sensor on-board electronics |
| LED driver type | Integrated high-efficiency (>97%) DC LED driver |
| max. drive voltage | 63 Vdc |
| max. drive current | 1850 mA |
| max. power | 80 W |
| SIM card | Global M2M eSIM (inc.), NanoSIM (opt.) |
| Global Navigation Satellite System (GNSS) | GPS, BeiDou, Galileo, GLONASS, QZSS |
| Over-the-Cable updateable | Yes (USB-programming device optional) |
| Over-the-Air updateable | Yes [1] |
| Remote monitoring and configuring | Optional [2] |
| Time and date | Astronomical clock |
| Lighting scheme | Automatic adaption to sunset and sunrise |
| Dimming scheme | HelioSyncâ„¢ Algorithmic Dimming |
| Smart city ready | Yes |
| Enclosure | Integrated in Soluxio Control Unit enclosure |
| Service plan [2] | 5 years included |
Lighting |
|
| Light fixture | LUX-A |
| Lighting scheme | Automatic adaption to sunset and sunrise |
| Light fixture power | from 5 W to max. 80 W |
| Max. efficacy | 192 lm/W |
| Color temperature | 3000K, 4000K, NatureGuardâ„¢ |
